General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Frequency stability
± 0.5 p.p.m.
Tuning steps
?
Memories
100 channels in 1 bank(s)

Receiver

RX-range
0.5-30 MHz
Modulations
AM   USB   LSB
Sensitivity
SSB
0.5-1.8 MHz: 3 µV
1.8-30 MHz: 1 µV
AM
0.5-1.8 MHz: 10 µV
1.8-30 MHz: 4 µV

All 12 dB SINAD
Selectivity
SSB: 2.4 kHz (-6 dB) / 4.5 kHz (-60 dB)
AM: 6 kHz (-6 dB) / 18 kHz (-60 dB)
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 71.75 MHz
2nd: 455 kHz
Image rejection
> 70 dB
Audio output
2 W (8 ohm, 10%), 4 W (4 ohm, 10%)

Transmitter

TX-range
1.6-30 MHz
Modulations
AM   USB   LSB
RF-output
SSB: 100 W, AM: 40 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC ± 15%
Current drain RX
1.2 A
TX
20 A

Physical

Dimensions (w×h×d)
178 × 58 × 228 mm (7.01 × 2.28 × 8.98 in) protrusions not included
Weight
2.70 kg (6.0 lbs)
Form factor
Mobile
Manufactured
Between 20xx and 20xx

Other features

Usage
Amateur / Ham radio operators
Features + options
Detachable front panel
Accessories
-
RigReference ID
5468
MPN
ALINCO-DX-000701
