General characteristics

HAM bands
11m (CB)
Frequency stability
?
Tuning steps
Channelized
Memories
23 channels in 1 bank(s)

Receiver

RX-range
11m
Modulations
AM
Sensitivity
1 µV
Selectivity
?
Filters
?
Receiver system
tubes
IF-frequencies
?
Image rejection
?
Audio output
2 W

Transmitter

TX-range
11m
Modulations
AM
RF-output
5 W

Connections

Antenna
SO-239
Impedance
?
Other
-

Electrical

Power requirements
Mains
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
305 × 127 × 216 mm (12.01 × 5.00 × 8.50 in)
Weight
?
Form factor
Base Station
Manufactured
Between 1964 and 196x in USA

Other features

Usage
Citizen Band (27Mc)
Features + options
Illuminated S-Meter
Squelch control
Accessories
-
RigReference ID
5522
MPN
LAFAYETTE-HE-000020C
