General characteristics

HAM bands
2m  70cm
Frequency stability
± 2.5 p.p.m.
Tuning steps
25 / 12.5 kHz
Memories
16 channels in 1 bank(s)

Receiver

RX-range
146-174 MHz
450-470 MHz
Modulations
FM
Sensitivity
≤0.251 µV / 0.282 µV
Selectivity
65 dB
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
0.5 W

Transmitter

TX-range
146-174 MHz
450-470 MHz
Modulations
FM
RF-output
5 / 4 / 2 W

Connections

Antenna
-
Impedance
50Ω
Other
-

Electrical

Power requirements
7.4V, 1650mAh (Li-Ion Battery)
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
113 × 54 × 35 mm (4.45 × 2.13 × 1.38 in)
Weight
280 gr (9.9 oz)
Form factor
Handheld
Manufactured
Between 201x and 201x in China

Other features

Usage
Commercial / Land mobile communication
Features + options
Compliant with MIL-STD 810 C/D/E/F
Accessories
-
RigReference ID
5640
MPN
HYTERA-TC-000508
