The PRC-10 was designed for use in the “Infantry Band” or 38-54.9 MC for use in command, control and coordination among infantry units.

General characteristics

HAM bands
6m
Frequency stability
?
Tuning steps
Continuous
Memories
?

Receiver

RX-range
38-55 MHz
Modulations
FM
Sensitivity
0.7 µV
Selectivity
75 kHz @ -6 dB
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
38-55 MHz
Modulations
FM
RF-output
0.9 W

Connections

Antenna
BNC + Proprietary (military)
Impedance
50Ω
Other
-

Electrical

Power requirements
Battery pack
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
265 × 77 × 470 mm (10.43 × 3.03 × 18.50 in)
Weight
8.42 kg (18.6 lbs)
Form factor
Portable
Manufactured
Between 195x and 19xx in USA

Other features

Usage
Military communication
Features + options
-
Accessories
-
RigReference ID
6223
MPN
MILITARY-RT-000176-/-PRC-10
