General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
5 kHz
Memories
?

Receiver

RX-range
144-146 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
10.695 MHz / 455 kHz
Image rejection
?
Audio output
500 mW

Transmitter

TX-range
144-146 MHz
Modulations
FM
RF-output
150 mW / 1.5 W

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
5.5-11 V DC
Current drain RX
150 mA
TX
550 mA max

Physical

Dimensions (w×h×d)
60 × 158 × 38 mm (2.36 × 6.22 × 1.50 in) with BA-2
Weight
370 gr (13.1 oz) with BA-2
Form factor
Handheld
Manufactured
Between 1985 and 198x

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
6601
MPN
DAIWA-MT-000020
