*High performance SDR core circuit design
*New spectrum display function
*Added AM broadcast receiving mode *Added CW Trainer function (supports full
insertion) *Adaptive speech noise reduction
*HF continuous reception
*Support for amateur data communication
*Support computer control
General characteristics
- HAM bands
- 80m 40m 20m 15m
- Frequency stability
- ≥ 1.5 p.p.m. after warm-up (30 minutes)
- Tuning steps
- ?
- Memories
- ?
Receiver
- RX-range
- 0.5-30 MHz (continuous)
- Modulations
- AM CW USB LSB
- Sensitivity
- ≥ 0.45 µV
- Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- 0.5 W
Transmitter
- TX-range
- 80-15m
- Modulations
- CW USB LSB
- RF-output
- 5 W
Connections
- Antenna
- BNC
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 13.8 V DC
- Current drain RX
- 500 mA
- TX
- 2.5 A max
Physical
- Dimensions (w×h×d)
- 97 × 40 × 155 mm (3.82 × 1.57 × 6.10 in)
- Weight
- ?
- Form factor
- Portable
- Manufactured
- Between 2022 and 20xx in China
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 6619
- MPN
- XIEGU-G000001M
