General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
5 kHz
Memories
?

Receiver

RX-range
143.5-148.5 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
143.5-148.5 MHz
Modulations
FM
RF-output
0.5-35 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
1.3 A
TX
Max 10 A

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Base Station
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2492
MPN
CLEGG-FM-DX

Manuals, diagrams and brochures

Clegg FM-DX Owner's Manual PDF - 1.36 MB, submitted by Minicowman

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Clegg FM-DX. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices:

Year Historic price Condition Submitted by
