General characteristics

HAM bands
160m  80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
Continuous
Memories
None

Receiver

RX-range
10-160 m
Modulations
AM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Connections

Antenna
BNC + Clamps / screws
Impedance
?
Other
-

Electrical

Power requirements
Mains
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
432 × 266 × 381 mm (17.01 × 10.47 × 15.00 in)
Weight
16.00 kg (35.3 lbs)
Form factor
Base Station
Manufactured
Between 1955 and 19xx in USA

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2514
MPN
COLLINS-000075A-4

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Collins 75A-4. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Collins 75A-4 is around:

  • USD 295.00 ~ USD 205.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2021 USD 300.00 Used / Good WILKEY
2018 USD 250.00 Used / Good Tony
