XTAL or VFO. Noise limiter. 100 KHz calibrator. 6DQ5 final New price 1961: $376.25
General characteristics
- HAM bands
- 80m 40m 20m 15m 6m 10m
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- ?
Receiver
- RX-range
- 10-80 m/6 m
- Modulations
- AM CW SSB
- Sensitivity
- 1 µV (6dB S/N)
- Selectivity
- 3 kHz (-6 dB), 14 kHz (-60 dB)
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- 15-80 m: >50 dB
- Audio output
- ?
Transmitter
- TX-range
- 10-80 m/6 m
- Modulations
- AM CW
- RF-output
- 60 W
Connections
- Antenna
- -
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- External PSU (12V DC or mains)
- Current drain RX
- Max 4.7 A @ 12.6 VDC
- TX
- ?
Physical
- Dimensions (w×h×d)
- ?
- Weight
- 11.00 kg (24.3 lbs)
- Form factor
- Unknown
- Manufactured
- Between 19xx and 196x in USA
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 2689
- MPN
- GONSET-G-000076
