General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
143.975-148.025 MHz
Modulations
AM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
XTAL or VFO
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
143.975-148.025 MHz
Modulations
AM   CW   SSB
RF-output
SSB: 20 W (PEP input), AM: 6 W (input)

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
Separate PSU's attaches to the back: Mains or 12.6V DC
Current drain RX
?
TX
Max 8 A @ 12.6 VDC

Physical

Dimensions (w×h×d)
241 × 140 × 183 mm (9.49 × 5.51 × 7.20 in)
Weight
4.58 kg (10.1 lbs)
Form factor
Base Station
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2693
MPN
GONSET-SIDEWINDER-000900A
