2 x 6146 finals

General characteristics

HAM bands
80m  40m  20m  15m  10m
Frequency stability
≥ 100 Hz drift/hour after warm-up, ≥ 100 Hz/10% power line variation
Tuning steps
?
Memories
?

Transmitter

TX-range
10-80 m
Modulations
CW   USB   LSB
RF-output
80-15m: 100W, 10m: 80W

Connections

Antenna
-
Impedance
50/75Ω
Other
-

Electrical

Power requirements
Mains (120-240 V AC)
Current drain RX
-
TX
260 W max

Physical

Dimensions (w×h×d)
378 × 143 × 340 mm (14.88 × 5.63 × 13.39 in)
Weight
12.02 kg (26.5 lbs)
Form factor
Unknown
Manufactured
Between 1966 and 1975 in USA

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2945
MPN
HEATHKIT-SB-000401

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Heathkit SB-401. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Heathkit SB-401 is around:

  • USD 4.00 ~ USD 5.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2001 USD 150.00 Used / Good ZedderBRL
2001 USD 150.00 Used / Good ZedderBRL
1982 USD 349.00 Used / Good Mark
