General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
144-148 MHz
Modulations
FM   CW   SSB
Sensitivity
FM: More than 30 dB S+N+D/N+D at 1 µV
SSB/CW: <0.5 µV (10 dB S+N/N)
Selectivity
FM: >15 kHz (-6 dB), <30 kHz (-60 dB)
SSB/CW: >2.4 kHz (-6 dB), <4.8 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
>60 dB
Audio output
?

Transmitter

TX-range
144-148 MHz
Modulations
FM   CW   SSB
RF-output
FM/CW: 1-10 W, SSB: 10 W PEP

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC or mains
Current drain RX
0.9-1.1 A
TX
1.8-3.3 A

Physical

Dimensions (w×h×d)
240 × 110 × 264 mm (9.45 × 4.33 × 10.39 in)
Weight
6.10 kg (13.5 lbs)
Form factor
Unknown
Manufactured
Between 197x and 197x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
NB, VOX, dimmer
Accessories
-
RigReference ID
2983
MPN
ICOM-IC-000211

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-211. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-211 is around:

  • USD 99.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2015 USD 200.00 Used / Mint OldBoss
