General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
?
Memories
20 channels in 1 bank(s)

Receiver

RX-range
144-146 / 430-440 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 / 430-440 MHz
Modulations
FM
RF-output
High: 5/5 W, Low: 0.5/0.5 W

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
6.3-16V DC
Current drain RX
12-100 mA
TX
Max 1.5 A

Physical

Dimensions (w×h×d)
58 × 179 × 30 mm (2.28 × 7.05 × 1.18 in)
Weight
520 gr (1.1 lbs) with PB-6
Form factor
Handheld
Manufactured
Between 1989 and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
Twin RX
Accessories
-
RigReference ID
3371
MPN
KENWOOD-TH-000075E

Manuals, diagrams and brochures

Kenwood TH-75 Schematic Diagram PDF - Unknown size, submitted by RigReference
Kenwood TH-75 Service Manual PDF - Unknown size, submitted by RigReference
Kenwood TH-75 User Manual PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Kenwood TH-75E. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Kenwood TH-75E is around:

  • EUR 162.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 EUR 170.00 Used / Okay Francisco
