General characteristics

HAM bands
160m  80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-160 m
Modulations
CW   USB   LSB   FSK
Sensitivity
0.33 µV for 10 dB S+N/N at 10m (2 kHz bandwidth)
Selectivity
SSB: 2 kHz, 1.5:1 (-6 dB)
FSK: 1200 Hz, 2:1

Optional:
CW: 400 Hz, 4:1 and 300 Hz, 2:1
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
> 60 dB
Audio output
1 W

Transmitter

TX-range
10-160 m
Modulations
CW   USB   LSB   FSK
RF-output
1-150 W (130 W max above 28 MHz)

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
Mains (115/230 V, 50-400 Hz)
Current drain RX
100 W
TX
400 W

Physical

Dimensions (w×h×d)
413 × 184 × 356 mm (16.26 × 7.24 × 14.02 in)
Weight
15.90 kg (35.1 lbs)
Form factor
Base Station
Manufactured
Between 1969 and 197x in USA

Other features

Usage
Amateur / Ham radio operators
Features + options
Dual VFO, built-in keyer and full QSK Advanced features for such an old radio.
60 dB attenuator
Accessories
-
RigReference ID
3969
MPN
SIGNAL/ONE-CX-000007

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
My CX-7 ( with the orange display) 7 years ago by j.charos
