General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
144-146 / 430-440 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 / 430-440 MHz
Modulations
FM
RF-output
High: 50/40 W, Low: 5/5 W

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
600 mA
TX
Hi 10.5 A, Lo 3.5 A

Physical

Dimensions (w×h×d)
150 × 50 × 205 mm (5.91 × 1.97 × 8.07 in)
Weight
2.00 kg (4.4 lbs)
Form factor
Mobile
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
Twin RX
Accessories
-
RigReference ID
4076
MPN
STANDARD-C-005200ED
