General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
10 channels in 1 bank(s)

Receiver

RX-range
144-146 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
1 TX channel. XTAL
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 MHz
Modulations
FM
RF-output
50 mW

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
4.8-6V DC
Current drain RX
18-80 mA
TX
60 mA

Physical

Dimensions (w×h×d)
70 × 120 × 37 mm (2.76 × 4.72 × 1.46 in)
Weight
290 gr (10.2 oz) incl. batteries
Form factor
Handheld
Manufactured
Between 19xx and 19xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4097
MPN
STANDARD-C-000800

Manuals, diagrams and brochures

Standard C-800 Manual (German) PDF - 3.25 MB, submitted by Gerd
