The Fair Mate HP-2000 is really an AOR AR-2000.

General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
user-selectable in any steps of 5 kHz and 12.5 kHz up to 995 kHz kHz
Memories
1000 channels in 10 bank(s) @ 20 channels/second

Receiver

RX-range
0.5-1300 MHz
Modulations
AM   FM   W-FM
Sensitivity
Low Band AM: 10dB S/N 0.7 - 1.0µV
N-FM: 12dB Sinad 0.5µV
W-FM: 20dB S/N 1.0µV
High band : N-FM: 12dB Sinad 0.7 - 1.0µV
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
100 mW

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
4.8-6V DC (4R6/AA) or 11-15V DC external
Current drain RX
80-100 mA
TX
-

Physical

Dimensions (w×h×d)
65 × 170 × 35 mm (2.56 × 6.69 × 1.38 in)
Weight
300 gr (10.6 oz) without batteries
Form factor
Handheld
Manufactured
Between 199x and 199x

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
5368
MPN
FAIR-MATE-HP-002000

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Fair Mate HP-2000. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Fair Mate HP-2000 is around:

  • USD 6.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
1993 USD 350.00 New / Mint jr6553
