General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
Crystal controlled
Memories
12 channels in 1 bank(s)

Receiver

RX-range
144-148 MHz
Modulations
FM
Sensitivity
0.4 µV for 20 dB quieting
Selectivity
7 kHz @ -6 dB, 16 kHz @ -50 dB
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
10.7 MHz / 455 kHz
Image rejection
45 dB
Audio output
3 W @ 10% THD, 5 W max.

Transmitter

TX-range
144-148 MHz
Modulations
FM
RF-output
20 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
11-14.5 V DC
Current drain RX
180-800 mA
TX
5 A max

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Mobile
Manufactured
Between 197x and 197x

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
5977
MPN
REGENCY-HR-000212

Manuals, diagrams and brochures

Regency HR-212 Service Manual PDF - 3.50 MB, submitted by Pancho Cheja
