General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  6m  2m  1.25m  70cm  33cm  23cm  10m  4m
Frequency stability
≤ 2.5 p.p.m. after 5 min. warm-up
Tuning steps
?
Memories
2000 channels in 40 bank(s)

Receiver

RX-range
0.1-1300 MHz
Modulations
AM   AM-sync   FM   CW   SSB   USB   DMR   D-STAR   P25   APCO-25   GMSK
Sensitivity
530 kHz - 18 MHz: 0.71 µV (12 dB SINAD)
18 - 1300 MHz: 0.32 µV (12 dB SINAD)
Selectivity
?
Filters
?
Receiver system
Direct, double or triple conversion depending on selected range
IF-frequencies
1st: 1.705 GHz
Image rejection
?
Audio output
1 W internal speaker, 3.5mm jacks

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
10.8-16 V DC
Current drain RX
750 mA
TX
-

Physical

Dimensions (w×h×d)
178 × 50 × 215 mm (7.01 × 1.97 × 8.46 in)
Weight
1.50 kg (3.3 lbs)
Form factor
Base Station
Manufactured
Between 2014 and 20xx

Other features

Usage
Amateur / Ham radio operators
Features + options
Micro-USB for receiver control with command list
Support for the following digital modes:
- DMR (Digital Mobile Radio)
- dPMR (Digital Private Mobile Radio)
- D-Star
- APCO-25
- NXDN
- Yaesu Digital (System Fusion)
- Alinco Digital
- Digital-CR
- AOR G4GUO (as used in ARD9000/9800)
Accessories
-
RigReference ID
6083
MPN
AOR-AR-DV000001
