General characteristics

HAM bands
80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  6m  10m
Frequency stability
?
Tuning steps
0.01 / 0.1 / 1 / 10 / 100 kHz
Memories
100 channels in 1 bank(s)

Receiver

RX-range
30 kHz - 54 MHz
Modulations
AM   FM   CW   SSB
Sensitivity
0.2 µV 10 dB
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
1st: 45 MHz
2nd: 12 MHz
3rd: 455 kHz (FM-only)
Image rejection
70 dB
Audio output
internal speaker

Transmitter

TX-range
80-6 m
Modulations
FM   CW   SSB
RF-output
3-15 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC
Current drain RX
700 mA
TX
4 A

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Mobile
Manufactured
Between 2014 and 20xx in China

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
6322
MPN
CHINESE-KN-000850

Manuals, diagrams and brochures

KN-850 QRP transceiver Instructions / manual PDF - 1.19 MB, submitted by RigReference
