General characteristics

HAM bands
6m
Frequency stability
?
Tuning steps
?
Memories
12 channels in 1 bank(s)

Receiver

RX-range
6m
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
XTAL
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
6m
Modulations
FM
RF-output
High: 10 W, Medium: 1 W, Low: 0.1 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
12V DC
Current drain RX
?
TX
Max 2.5 A

Physical

Dimensions (w×h×d)
?
Weight
2.00 kg (4.4 lbs)
Form factor
Mobile
Manufactured
Between 197x and 197x in discontinued in the early seventies

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
6427
MPN
KDK-FM-000050-10LA
