General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Frequency stability
?
Tuning steps
Continuous
Memories
None

Receiver

RX-range
0.54-1.6 / 1.75-4.9 / 4.8-12.6 / 12.5-34 MHz
Modulations
AM   CW   SSB
Sensitivity
?
Selectivity
5 kHz (-6 dB)
2.5 kHz (-6 dB)
500 Hz (-6 dB)
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 1.65 MHz
2nd: 50 kHz
Image rejection
?
Audio output
3.2 W external only

Connections

Antenna
Clamps / screws
Impedance
50-600Ω
Other
-

Electrical

Power requirements
Mains (115 / 230 V AC)
Current drain RX
85 W max
TX
-

Physical

Dimensions (w×h×d)
476 × 203 × 248 mm (18.74 × 7.99 × 9.76 in)
Weight
13.20 kg (29.1 lbs)
Form factor
Base Station
Manufactured
Between 19xx and 19xx in USA

Other features

Usage
Amateur / Ham radio operators
Features + options
ANL
Accessories
-
RigReference ID
6468
MPN
HALLICRAFTERS-SX-000122A

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Hallicrafters SX-122A. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Hallicrafters SX-122A is around:

  • USD 161.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2014 USD 405.00 Used / Good KV4NK
