The Sony ICF-SC1 Wavehawk is a capable scanner covering 25 to 1300 MHz (less cellular) in AM, FM-N and FM-W modes. It has 300 memory channels. The Intelligent Active Memory System memorizes a frequency which has been received for five seconds or longer. Other features include: backlit LCD, key lock and skip function. Scanning modes include: Band Scanning, Programmable Scanning, Memory Scanning, Intelligent Memory Scanning and Priority Scanning. The controls are easy to use and you also get one button access to public service categories (police, fire emergency, VHF air, UHF air, marine, FM broadcast, VHF TV sound and UHF TV sound).


The Sony ICF-SC1 is similar to the Sony ICF-SC1 PC, but doesn't have the PC interface support.

General characteristics

HAM bands
11m (CB)  6m  2m  1.25m  70cm  33cm  23cm  10m  4m
Frequency stability
?
Tuning steps
?
Memories
300 channels in 1 bank(s)

Receiver

RX-range
25-1300 MHz (Cellular blocked in the US)
Modulations
AM   N-FM   W-FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
6V DC (4 x LR6/AA or external adapter)
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
64 × 177 × 44 mm (2.52 × 6.97 × 1.73 in)
Weight
255 gr (9.0 oz)
Form factor
Handheld
Manufactured
Between 2002 and 200x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
AC-E60HG AC adapter
RigReference ID
6513
MPN
SONY-ICF-SC000001

Manuals, diagrams and brochures

Sony Icfsc1 PC Wideband Scanner Service Manual PDF - 1.89 MB, submitted by Berend
