General characteristics

HAM bands
None
Frequency stability
± 3 p.p.m.
Tuning steps
25 kHz (channelized)
Memories
?

Receiver

RX-range
156.050-163.275 MHz
65-108 MHz
Modulations
FM   W-FM
Sensitivity
Voice
0.25 µV for 12 dB SINAD
DSC
0.5 µV for 12 dB SINAD
Selectivity
12 kHz @ -6 dB / 25 kHz @ -60 dB
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 38.85 MHz
2nd: 450 kHz
Image rejection
70 dB
Audio output
700 mW

Transmitter

TX-range
156.025-161.600 MHz
Modulations
FM
RF-output
1 / 2.5 / 6 (5) W

Connections

Antenna
SMA
Impedance
50Ω
Other
-

Electrical

Power requirements
7.4 V DC
Current drain RX
380 mA
TX
1.6 A max

Physical

Dimensions (w×h×d)
66 × 138 × 38 mm (2.60 × 5.43 × 1.50 in)
Weight
310 gr (10.9 oz)
Form factor
Portable
Manufactured
Between 201x and 202x

Other features

Usage
Marine / Navy
Features + options
GPS
Accessories
-
RigReference ID
6606
MPN
STANDARD-HORIZON-HX000890
