Radtel CB-10

General characteristics

HAM bands

11m (CB)

Frequency stability

±5.0 ppm

Tuning steps

?

Memories

?

Receiver

RX-range

26.965-27.405 MHz

Modulations

AM   FM

Sensitivity

?

Selectivity

?

Filters

?

Receiver system

?

IF-frequencies

?

Image rejection

?

Audio output

?

Transmitter

TX-range

26.965-27.405 MHz

Modulations

AM   FM

RF-output

4 W

Connections

Antenna

-

Impedance

?

Other

-

Electrical

Power requirements

12 V

Current drain RX

0.3 A squelched, 0.8 A max. volume

TX

2 A max.

Physical

Dimensions (w×h×d)

165 × 44 × 67 mm (6.50 × 1.73 × 2.64 in)

Weight

444 gr (15.7 oz)

Form factor

Handheld

Manufactured

Between 20xx and 20xx in China

Other features

Usage

Citizen Band (27Mc)

Features + options

27 MHz CB handheld
AM / FM
CTCSS in FM mode
PLL synthesiser
SO-239 antenna connector
4100 mAh battery

Accessories

-

RigReference ID

6745

MPN

RADTEL-CB-000010

Manuals, diagrams and brochures

No manuals yet for the Radtel CB-10. Have a PDF of the user manual, service manual, or schematic? Upload it and help the next operator.



Upload relevant documents

Reviews

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Radtel CB-10. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the Radtel CB-10 in Good condition is around:

• USD 127

Price History Chart

These estimates are based on the following prices:
