Steps: 5-25 kHz
Intermodulation: 65 / 60 dB
Spurious rejection: 70 dB
Operating temperature: -20 to +60 °C
Other official image lists 220-260 MHz
General characteristics
- HAM bands
- 2m 1.25m 70cm
- Frequency stability
- ±2.5 ppm
- Tuning steps
- ?
- Memories
- 200 channels in bank(s)
Receiver
- RX-range
- 136-174 / 220-270 / 350-390 / 400-480 MHz
- Modulations
- FM N-FM
- Sensitivity
- Wide: 0.25 µV or less
Narrow: 0.35 µV or less - Selectivity
- Adjacent channel: 70 dB (wide) / 60 dB (narrow)
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- 2 W or more (10%)
Transmitter
- TX-range
- 136-174 / 220-270 / 350-390 / 400-480 MHz
- Modulations
- FM N-FM
- RF-output
- 25 W (VHF) / 20 W (UHF)
Connections
- Antenna
- -
- Impedance
- ?
- Other
- -
Electrical
- Power requirements
- 13.8 V DC ±15%
- Current drain RX
- ?
- TX
- ?
Physical
- Dimensions (w×h×d)
- 98 × 43 × 136 mm (3.86 × 1.69 × 5.35 in)
- Weight
- 448 gr (15.8 oz)
- Form factor
- Mobile
- Manufactured
- Between 20xx and 20xx in China
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Mini quad-band mobile
Quad display
200 channels
CTCSS / DCS / 5-tone / 2-tone / DTMF - Accessories
- -
- RigReference ID
- 6812
- MPN
- ZASTONE-MP000380
Manuals, diagrams and brochures
-
No manuals yet for the Zastone MP380+. Have a PDF of the user manual, service manual, or schematic? Upload it and help the next operator.
- Upload relevant documents
Reviews
Be the first to review the Zastone MP380+
No reviews yet. Share your experience and earn +10 reputation.
Write the first reviewNew and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Zastone MP380+. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on similar Transceiver equipment, the estimated value of the Zastone MP380+ is around:
- USD 203 ~ USD 377
This estimate is based on similar equipment and may not reflect the exact value of this model.
These estimates are based on the following prices:
