The Rohde & Schwarz ESM-180 has 5 bands: 30-42,5 / 42,5-61 / 61-87,5 / 87,5-126 and 126-180 MHz

General characteristics

HAM bands
6m  2m  4m
Frequency stability
± 0.01 %, crystal controlled
Tuning steps
40 / 200 kHz
Memories
None

Receiver

RX-range
30-180 MHz in 5 bands
Modulations
AM   FM   CW
Sensitivity
N-AM, band 1-4: 2.5 µV
N-AM, band 5: 5 µV
FM, band 1-4: 2 µV
FM, band 5: 4 µV
Selectivity
Narrow-band: 0.3-3 kHz
Wide-band: 0.03-15 kHz
Filters
?
Receiver system
Single / Double conversion superheterodyne
IF-frequencies
21.4 / 3.4 MHz
Image rejection
Band 1-4: 80 dB, band 5: 60 dB
Audio output
500 mW or AF output socket

Connections

Antenna
Proprietary
Impedance
60Ω
Other
Dezifix B (R&S)

Electrical

Power requirements
Mains
Current drain RX
110 VA
TX
-

Physical

Dimensions (w×h×d)
540 × 234 × 378 mm (21.26 × 9.21 × 14.88 in)
Weight
28.00 kg (61.8 lbs)
Form factor
Base Station
Manufactured
Between 196x and 196x in West Germany

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3763
MPN
ROHDE-SCHWARZ-ESM-000180

Manuals, diagrams and brochures

Rohde-Schwarz ESM-180 Instruction Book PDF - 1.10 MB, submitted by Eric R

Upload relevant documents

Reviews & stories

Rating Title Submitted
Lucky Moment 9 years ago by gurugiyang

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Rohde & Schwarz ESM-180. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Rohde & Schwarz ESM-180 is around:

  • EUR 805.00 ~ EUR 428.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2019 EUR 475.00 Used / Good eBay
2019 EUR 893.00 Used / Good eBay
