General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
100-230 / 300-530 / 810-1000 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 / 430-440 MHz (Europe)
Modulations
FM
RF-output
High: 50/35 W, Low: ?/? W

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
Max 9.5 A

Physical

Dimensions (w×h×d)
100 × 30 × 138 mm (3.94 × 1.18 × 5.43 in)
Weight
640 gr (1.4 lbs)
Form factor
Mobile
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4371
MPN
YAESU-FT-000090R
