Military AN/GRC-9

Mobile Shortwave Transceiver

Specs Manuals (0) Reviews (0) Prices (1) Compare

Add a review (+10 rep) Own this rig? Add it to your shack

The Military AN/GRC-9 is a 2-12 MHz transceiver. It has a single conversion receiver system with an IF frequency of 456 kHz. The RF output is 3.5-15 W. It operates on 6, 12 or 24V DC and weighs 18 kg.

General characteristics

HAM bands: ?
Frequency stability: ?
Tuning steps: ?
Memories: ?

Receiver

RX-range: 2-12 MHz
Modulations: AM CW
Sensitivity: ?
Selectivity: ?
Filters: ?
Receiver system: Single conversion
IF-frequencies: 456 kHz
Image rejection: ?
Audio output: ?

Transmitter

TX-range: 2-12 MHz
Modulations: AM CW
RF-output: 3.5-15 W

Connections

Antenna: Clamps / screws + Proprietary (military)
Impedance: 50Ω
Other: -

Electrical

Power requirements: 6, 12 or 24V DC
Current drain RX: ?
TX: ?

Physical

Dimensions (w×h×d): ?
Weight: 18.00 kg (39.7 lbs)
Form factor: Mobile
Manufactured: Between 195x and 197x in USA

Other features

Usage: Military communication
Features + options: -
Accessories: -
RigReference ID: 5207
MPN: MILITARY-AN/GRC-000009

We do our best to be accurate, but if you've spotted something wrong or incomplete, please let us know!

Manuals, diagrams and brochures

: No manuals yet for the Military AN/GRC-9. Have a PDF of the user manual, service manual, or schematic? Upload it and help the next operator.

: Upload relevant documents

Reviews

Be the first to review the Military AN/GRC-9

No reviews yet. Share your experience and earn +10 reputation.

Write the first review

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Military AN/GRC-9. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the Military AN/GRC-9 in Good condition is around:

EUR 75

Price History Chart

These estimates are based on the following prices:

Year	Historic price	Condition	Submitted by
2002	EUR 75.00	Used / Good	elmer
