General characteristics

HAM bands
2m  70cm
Frequency stability
±2.5ppm
Tuning steps
5 / 6.25 / 10 / 12.5 / 25 / 50 / 100 kHz
Memories
999 channels in 1 bank(s)

Receiver

RX-range
136-174 / 400-470 MHz
136-174 / 400-480 MHz
136-174 / 420-520 MHz
144-146 / 430-440 MHz
76-108 MHz
Modulations
FM   N-FM
Sensitivity
0.25µV (12dB SINAD)
Selectivity
12.5 / 25 kHz
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
500mW max

Transmitter

TX-range
136-174 / 400-470 MHz
136-174 / 400-480 MHz
136-174 / 420-520 MHz
144-146 / 430-440 MHz
Modulations
FM   N-FM
RF-output
VHF: 5W, UHF: 4W max

Connections

Antenna
SMA
Impedance
50Ω
Other
-

Electrical

Power requirements
7.4V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
62 × 125 × 34 mm (2.44 × 4.92 × 1.34 in)
Weight
490 gr (1.1 lbs)
Form factor
Handheld
Manufactured
Between 201x and 20xx in China

Other features

Usage
Amateur / Ham radio operators
Features + options
Dual display
VOX
DTMF
Stopwatch
Alarm
SOS function
Accessories
-
RigReference ID
6100
MPN
WOUXUN-KG-UV000008D

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Wouxun KG-UV8D. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Wouxun KG-UV8D is around:

  • USD 85.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2015 USD 119.00 New / Mint drguyor
