General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  6m  10m
Frequency stability
≥ 1 p.p.m. after warm-up (20 minutes)
Tuning steps
1 Hz
Memories
?

Receiver

RX-range
0.5-30 / 50-54 MHz
Modulations
AM   FM   CW   USB   LSB   RTTY
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
Internal speaker

Transmitter

TX-range
10-160 m + WARC / 6 m
Modulations
AM   FM   CW   USB   LSB   RTTY
RF-output
5 W on battery, 10 W on external power

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
9-15 V DC
Current drain RX
550 mA
TX
3 A max

Physical

Dimensions (w×h×d)
180 × 86 × 49 mm (7.09 × 3.39 × 1.93 in)
Weight
?
Form factor
Portable
Manufactured
Between 2022 and 20xx in China

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
6620
MPN
XIEGU-X006100

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Xiegu X6100. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Xiegu X6100 is around:

  • USD 499.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2023 USD 500.00 Used / Mint Adrian Gonzalez
