The Racal TRA-931 is a manpack HF transceiver. Frequency selection is done by way of 5 decade switches giving a 1 kHz resolution. A search knob allows further tuning within the 1 kHz range.
The TRA-931 housing is made from industrial strength plastic and is water tight. The front panel has 2 connectors for mic/phones/keyer, AF-gain knob, mode-knob and small battery voltage indicator. A number of antennas can be connected to the TRA-931 which can be tuned with an internal antenna tuner (TRA-931A). For ham use 2 BNC connectors for 1.6-3 and 3-30 MHz are very suitable.
Variants
TRA931: Syncal 30
TRA931A: As standard set plus auto ATU
TRA931AP: Programmable version of TRA931A
TRA931L: Low temperature version of TRA931 -40 dec C
TRA931P: Programmable Syncal 30 2-8 Mhz 49ch 20W **
TRA931PL: Low temperature version of TRA931P
TRA931PR: Capable of remote control
TRA931X: Multi-role Syncal 30
TRA931XH: Frequency Hopping version of TRA931
TRA931Y: As TRA931X but with component changes for operation at lower temperatures. -25 deg C
General characteristics
- HAM bands
- ?
- Frequency stability
- better than ±2 ppm
- Tuning steps
- 1 kHz
- Memories
- ?
Receiver
- RX-range
- 1.6-29.999 MHz
- Modulations
- AM CW USB LSB
- Sensitivity
- 1 µV for S/N > 10 dB
- Selectivity
- SSB: 2 kHz (-6 dB), 6 kHz (-40 dB)
AM: 10 kHz (-6 dB), 30 kHz (-55 dB) - Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 1.6-29.999 MHz
- Modulations
- AM CW USB LSB
- RF-output
- 5/20 W (PEP)
Connections
- Antenna
- BNC + Proprietary (military)
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 24V DC (operates down to 12V DC)
- Current drain RX
- 250 mA
- TX
- 4 A
Physical
- Dimensions (w×h×d)
- 366 × 116 × 275 mm (14.41 × 4.57 × 10.83 in)
- Weight
- 5.00 kg (11.0 lbs) in basic configuration
- Form factor
- Mobile
- Manufactured
- Between 197x and 19xx in Great Britain
Other features
- Usage
- Military communication
- Features + options
- -
- Accessories
- -
- RigReference ID
- 5250
- MPN
- RACAL-TRA-000931
