Radtel RT-20M

General characteristics

HAM bands

2m  70cm

Frequency stability

?

Tuning steps

?

Memories

999 channels in bank(s)

Receiver

RX-range

136-174 / 400-480 MHz
Airband AM 108-130 MHz
FM broadcast 64-108 MHz

Modulations

AM   FM   N-FM   W-FM

Sensitivity

0.22 µV (12 dB SINAD)

Selectivity

55 dB

Filters

?

Receiver system

?

IF-frequencies

?

Image rejection

?

Audio output

?

Transmitter

TX-range

136-174 / 400-480 MHz

Modulations

FM   N-FM

RF-output

25 W

Connections

Antenna

-

Impedance

?

Other

-

Electrical

Power requirements

?

Current drain RX

?

TX

?

Physical

Dimensions (w×h×d)

?

Weight

?

Form factor

Mobile

Manufactured

Between 20xx and 20xx in China

Other features

Usage

Amateur / Ham radio operators

Features + options

Dual-band mobile
Airband receive, NOAA weather alerts
FM radio
VOX, scrambler, TOT
High / low power, wide / narrow
Emergency alarm
Record and playback
Dual display, dual standby

Accessories

-

RigReference ID

6750

MPN

RADTEL-RT-000020M

Similar rigs

Manuals, diagrams and brochures

No manuals yet for the Radtel RT-20M. Have a PDF of the user manual, service manual, or schematic? Upload it and help the next operator.



Upload relevant documents

Reviews

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Radtel RT-20M. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the Radtel RT-20M in Good condition is around:

• USD 82

Price History Chart

These estimates are based on the following prices:
