Zastone KT-A16
Aviation Handheld Transceiver
Add a review (+10 rep) Own this rig? Add it to your shack
Operating temperature: -10 to +60 °C
General characteristics
- HAM bands
- ?
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- 200 channels in bank(s)
Receiver
- RX-range
- 108.000-136.99166 MHz
Weather 161.650-163.275 MHz - Modulations
- AM
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 118.000-136.99166 MHz
- Modulations
- AM
- RF-output
- 6 W
Connections
- Antenna
- -
- Impedance
- ?
- Other
- -
Electrical
- Power requirements
- 7.2 V, Li-ion 2000 mAh
- Current drain RX
- ?
- TX
- ?
Physical
- Dimensions (w×h×d)
- 65 × 112 × 25 mm (2.56 × 4.41 × 0.98 in)
- Weight
- 350 gr (12.4 oz) About, including battery
- Form factor
- Handheld
- Manufactured
- Between 20xx and 20xx in China
Other features
- Usage
- Air-to-air / air-to-ground communication
- Features + options
- Airband handheld transceiver
AM
200 channels
Three-channel display, 1.77 inch colour screen
Weather channels
Chinese / English menu
Desktop charger - Accessories
- -
- RigReference ID
- 6800
- MPN
- ZASTONE-KT-A000016
