Channel spacing: 25 / 20 / 12.5 kHz
PLL step: 2.5 / 5 / 6.25 / 10 / 12.5 / 20 / 25 / 30 / 50 kHz
Operating temperature: -20 to +60 °C
Also sold as a US version
General characteristics
- HAM bands
- 2m 70cm
- Frequency stability
- ±2.5 ppm
- Tuning steps
- ?
- Memories
- 200 channels in bank(s)
Receiver
- RX-range
- 144-148 / 430-440 MHz
- Modulations
- FM N-FM
- Sensitivity
- 0.25 µV (wide) / 0.35 µV (narrow), 12 dB SINAD
- Selectivity
- Adjacent channel: 60 dB
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- More than 2 W (8 ohm), distortion 5% or less
Transmitter
- TX-range
- 144-148 / 430-440 MHz
- Modulations
- FM N-FM
- RF-output
- 25 / 15 / 5 W
Connections
- Antenna
- -
- Impedance
- ?
- Other
- -
Electrical
- Power requirements
- 13.8 V DC ±15%
- Current drain RX
- ?
- TX
- ?
Physical
- Dimensions (w×h×d)
- 124 × 39 × 163 mm (4.88 × 1.54 × 6.42 in)
- Weight
- 640 gr (1.4 lbs)
- Form factor
- Mobile
- Manufactured
- Between 20xx and 20xx in China
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Dual-band FM mobile
CTCSS / DCS squelch
200 channels - Accessories
- -
- RigReference ID
- 6719
- MPN
- RETEVIS-RT000095
